COMPLETE  OUTBOARD ENGINE SYSTEMS

What is the difference in the "Premium vs Ultimate Kits?"

Sample

(Premium) You Build Kit


● The leg needs to have the bracket bolt attached and all
    grease points lubricated.

● Customer will need to attach engine with 4 supplied
   stainless bolts, 1 throttle cable and nut, add oil based on
   Honda manual or oil filler stick (crosshatch) markings
   depending on engine setup, and adjust the twist throttle
   for proper idling.

● Twist throttle may need to be rotated and positioned so
    that the cable is not binding, which effects the opening
    and closing of the throttle position. I commonly take off
    the sheath and run my wires in the tube and the throttle
    cable is tie wrapped in one spot on the tiller arm.

● Red and green kill switch wires need to connect to the
   53cc engine with the same colors. Honda 35cc engines
   will need the black from the engine to the green/red as it
   doesn't matter and a second line provided with the
   waterproof  plug, is run to one of the mounting bolts of the
   engine. Connectors are provided.
_______________________________________

● Engine trim angle needs to be adjusted to boat transom.
   4 Hex bolts are supplied in the bracket. You should be 5-7
   degrees trimmed upward so the bow rises and the kayak
   planes.

 ● Leg height needs to be adjusted so propeller sits about 2-
    4 inches below the bottom of the hull water line
    underneath in the non-turbulent water.

BUILD TIME VARIES FROM 30 MINUTES TO AN HOUR

Sample

(Ultimate) Ready to Run


● Kayak Buddys performs all of the following bullet points
   on the left to the clients who want the engine system built for
   them.

● All systems are available in RTR format as of 11/2019

We only charge a flat-fee of $100.00 to build, mount, and adjust all systems to the owners kayak or watercraft, if you bring it to the shop. This even includes the stabilzers and motor mounts.

This well worth the travel time if you are not sure of your skill set. But, either way Kayakbuddys can walk you through it over the phone, text, facetime, or skype. Whatever works for you.




COMPLETE 4 STROKE
PROPULSION SYSTEMS
WITH STANDARD or UPGRADED LEG

* shipping and tax will be added if your billing address is in Florida.
** a separate email invoice for shipping, tax, and insurance will follow.

*** Standard legs with the galvanized throttle system has been labeled as freshwater useage due to the ferrous metal corrosion that could happen with heavy salt water use if not lubricated properly. All ugraded systems can be used in either environments.

$ 569.00

35CC (1.3hp) GX Series
Honda Engine

4 STROKE - YOU BUILD (PREMIUM)



*Freshwater usage




* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Standard Throttle System
* 3 - Blade Prop
* 35CC Honda 4 Stroke
   Engine (OEM)
* Heavy-duty Clutch
___________________
*Shipping is additional and
will be billed separately.

$ 719.00

35CC (1.3hp) GX Series
Honda Engine

4 STROKE - YOU BUILD
(UPGRADED LEG)


**Fresh and Saltwater usage




* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Upgraded Throttle System
* 2 - Blade Prop and Collar
* 35CC Honda 4 Stroke
Engine (OEM)
* Heavy-duty Clutch
___________________
*Shipping is additional and
will be billed separately.

$ 819.00

35CC (1.3hp) GX Series
Honda Engine

4 STROKE - BUILT
(UPGRADED LEG)


**Fresh and Saltwater usage


Ready to Run (RTR)

* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Upgraded Throttle System
* 2 - Blade Prop and Collar
* 35CC Honda 4 Stroke
   Engine (OEM)
* Heavy-duty Clutch
___________________
Unit is built and adjusted for the customer. Ready to run. Just add oil and gas.

*Shipping is additional and
will be billed separately.

Order your 35cc engine system here...

$ 519.00

53CC (2.1hp) GXV Series
Huasheng EPA 4 Stroke

4 STROKE - YOU BUILD
(PREMIUM)



*Fresh water usage

** Available in February




* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Standard Throttle System
* 3 - Blade Prop
* 53CC Huasheng 4 Stroke
   Engine (OEM)
* Heavy-duty Clutch
___________________
*Shipping is additional and
will be billed separately.

$ 669.00

53CC (2.1hp) GXV Series
Huasheng EPA 4 Stroke

4 STROKE - YOU BUILD
(UPGRADED LEG)


**Fresh and Saltwater usage

*** Available in February




* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Upgraded Throttle System
* 3 - Blade Prop
* 53CC Huasheng 4 Stroke
   Engine (OEM)
* Heavy-duty Clutch
___________________
Unit is built and adjusted for the customer. Ready to run.

$ 769.00

53CC (2.1hp) GXV Series
Huasheng EPA 4 Stroke

4 STROKE - YOU BUILD
(UPGRADED LEG)


**Fresh and Saltwater usage

*** Available in February


Ready to Run (RTR)

* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Upgraded Throttle System
* 3 - Blade Prop and Collar
* 53CC Huasheng 4 Stroke          Engine (Non-branded)
* Heavy-duty Clutch
___________________
*Shipping is additional and
will be billed separately.

Order your 53cc engine system here...

COMPLETE 2 STROKE
PROPULSION SYSTEMS

* shipping and tax will be added if your billing address is in Florida.
** a separate email invoice for shipping, tax, and insurance will follow.

Oil mix is 50:1 for break-in
then mix 32:1 thereafter.

*** Standard legs with the galvanized throttle system has been labeled as freshwater useage due to the ferrous metal corrosion that could happen with heavy salt water use if not lubricated properly. All ugraded systems can be used in either environments.

$ 469.00

71CC Non-Branded Engine

2 STROKE - YOU BUILD (PREMIUM)


*Freshwater usage




* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Standard Throttle System
* 3 - Blade Pro
* 71CC Clone 2 Stroke Engine
   (Non-branded)
* Heavy-duty Clutch

___________________
*Shipping is additional and
will be billed separately.

$ 569.00

71CC Non-Branded Engine

2 STROKE - YOU BUILD (ULTIMATE)


*Freshwater usage


Ready to Run (RTR)

* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Standard Throttle System
* 3 - Blade Prop
* 71CC Clone 2 Stroke Engine
   (Non-branded)
* Heavy-duty Clutch

___________________
Unit is built and adjusted for the customer. Ready to run.

$ 669.00

71CC Non-Branded Engine

2 STROKE - YOU BUILD (UPGRADED LEG)

*Fresh and Saltwater usage


Ready to Run (RTR)

* Small Outboard Leg
* Stainless Hardware
* Oil Filled Lower Unit
* Upgraded Throttle System
* 3 - Blade Prop is retained for
   torque
* 71CC Clone 2 Stroke Engine
   (Non-branded)
* Heavy-duty Clutch
___________________
*Shipping is additional and
will be billed separately.

Order your 71cc engine system here...

All New Engines Need to Break-in

On all 4 stroke engines, it is imperative that you cycle the engines through full warm up and then for about 15 minutes (half throttle). Let the engine cool down and repeat the same procedure 2 more times and check oil levels. During this process cycle the throttle and rev it up occasionally and back to idle. Once complete, a load consisting of you driving the watercraft at varying throttle speeds in longer durations and positions helps seat rings and wear in the cylinder and sleeve for a long life. I would not run wide open immediately to allow the rings to seat properly. Working the throttle up to 3/4 is fine when initially breaking in the engine.

Check the oil level immediately and fill up to the upper level if needed. 30 weight oil works great in the warmer climates. Adjust weight if necessary depending on season. It is common for a bit of oil to be burnt as it will bypass the rings as it breaks-in.

Once you have a few hours on the engine, I normally fully drain all 4 strokes and refill them with new oil. Fresh oil is the key to engine longevity. Never run the engines on the low mark on the dipstick. Engine damage and seizing will occur. Protect the investment. Always check oil levels before and after every trip to maximize life on all size powerheads. Don't void warranties by being careless. No low oil shut-off switches are found on these small 4 strokes with the exception the Lifan 35cc we carry.  The larger 5 hp and up vertical engines commonly have this feature and a much larger oil sump. The safe zone for all Honda and non-branded small 4 strokes is to check your oil everytrip, and top off after a day of hard run time.


Mr. Matthew Pate, Owner

14605 SW 174 Terrace

Miami, Florida 33177

mattpate@comcast.net

(305) 926-2937

We pride ourselves on customer service. Please call or email us with any concerns or questions you may have on our engine legs and complete systems. We are here to help.

Send a message!

Build Notes

Below are a few commonly downloaded .pdf instructions to make the build process painless and simple.
